Fisher & Paykel Dishwasher Error Codes And What They Mean

2025-06-17

If your Fisher & Paykel dishwasher is flashing lights or displaying unfamiliar error codes, it’s signaling that something needs attention.

In this guide, we’ll explain the most common Fisher & Paykel dishwasher error codes—many of which can be resolved at home with just a few basic tools.

What Are Fisher & Paykel Dishwasher Error Codes?

Fisher & Paykel dishwashers use a system of digital displays and flashing indicator lights to communicate internal issues. Each code corresponds to a specific problem, such as a water leak, motor failure, or draining issue. Understanding these Fisher and Paykel dishwasher error codes gives you a head start on the solution and helps keep your dishwasher running efficiently.

Complete Fisher & Paykel Dishwasher Error Code Guide

Here’s a full list of Fisher & Paykel dishwasher error codes and what they mean:

F1 – Leak Detected
Water has entered the base of the unit and triggered the flood switch.

F2 – Motor Fault
The wash motor has stalled or failed.

F3 – Temperature Sensor Error
The thermistor (temperature sensor) is faulty or disconnected.

F4 – Heating Element Fault
The dishwasher isn’t heating water correctly—likely due to a faulty element or control board.

F5 – Lid Fault
The drawer lid is not sealing properly; lid actuators may be stuck or misaligned.

F6 – Water Fill Error
The unit is not receiving water; check the supply and inlet valve.

F7 – Drain Fault
The dishwasher is not draining—inspect the pump, drain hose, or filter.

F8 – Electrical Fault
There is a general electrical failure, often caused by a faulty controller.

F9 – Communication Fault
Loss of communication between the display and control modules.

U1 – Fill Timeout
The dishwasher took too long to fill—check for a kinked hose or clogged filter.

U2 – Loading Error
The dish drawer is imbalanced or overloaded.

U3 – Lid Sensor Fault
The sensor isn’t detecting the lid position; this could be due to water residue or misalignment.

How to Troubleshoot Fisher & Paykel Dishwasher Error Codes

Before you begin any repairs, gather the following:

User manual
Phillips and Torx screwdrivers
Multimeter (if you have one)
Flashlight
Towels
Tray or container to catch water

Step 1: Identify the Code

Check your display or light pattern and match it to the list above.

Step 2: Power Down the Unit

Always turn off the dishwasher at the circuit breaker before removing any parts.

Step 3: Apply the Fix

Here are the most common user-fixable problems:

Fixing F1 – Leak Detected
This error often results from spilled water or minor overflows inside the drawer compartment.
What to do:

• Pull out the drawer and dry the area underneath using towels or a sponge.

• If there’s water in the base pan, soak it up carefully and let the area air dry.

• Once completely dry, restore power and check if the error clears.

Fixing F2 – Motor Fault
While replacing a motor is best left to professionals, sometimes this code is triggered by something simple, like a blocked spray arm.
What to do:

• Remove and inspect the spray arms for food debris or hard water buildup.

• Rinse thoroughly and reattach.

• Try running a cycle again to see if the issue resolves.

Fixing F6 – Water Fill Error
This often occurs when the water supply is off or obstructed.
What to do:

• Make sure the water valve under your sink is fully open.

• Check the inlet hose for any kinks or bends.

• Unscrew and inspect the mesh filter where the hose connects—clean it if clogged with sediment.

Fixing F7 – Drain Fault
This code is commonly caused by a clog or partial blockage.
What to do:

• Remove the bottom drawer and inspect the drain area for trapped food or debris.

• Check the drain filter and rinse it under warm water.

• Make sure the drain hose is not kinked behind the unit or under the sink.

Fixing U1 – Fill Timeout
This is similar to F6 but is time-based. The dishwasher tried to fill and timed out.
What to do:

• Ensure the water supply is on and strong.

• Check for a blocked inlet screen and remove any debris.

Fixing U2 – Loading Error
This is often due to uneven weight or items preventing proper drawer movement.
What to do:

• Reposition heavy items so they’re evenly distributed.

• Make sure nothing is sticking out or interfering with the lid closing.

Fixing U3 – Lid Sensor Fault
Moisture or residue around the lid sensors can cause false readings.
What to do:

• Wipe down the lid area and drawer edges with a dry cloth.

• Let the unit sit with the drawer open for 20–30 minutes before restoring power.

FAQs About Fisher & Paykel Dishwasher Codes

Can I keep using the dishwasher with an error code?
No—error codes are a warning system. Ignoring them can cause more damage.

Why does the same code keep showing up?
Either the issue wasn’t fully resolved, or the component needs replacement. Some models may also require a reset.

How do I reset my Fisher & Paykel dishwasher?
Turn off the power at the circuit breaker for 30 minutes. Most codes will clear after power is restored.

Do single and double-drawer models use the same error codes?
Yes, the codes are the same, though part placement may vary between models.

Final Tip: How to Prevent Future Fisher & Paykel Dishwasher Error Codes with Simple Maintenance

To prevent future error codes, clean your dishwasher filters monthly, avoid overloading the drawers, and always use high-quality detergent. A few minutes of routine maintenance can save you hours of frustration later on.
